KL250A 2500KG Electric Tow Tug
| Characteristic | ||||
| 1.1 | Brand | KALLY | KALLY | |
| 1.2 | Model | ML200A | ML250A | |
| 1.3 | Power supply | Electric | Electric | |
| 1.4 | Operating type | Tow tugs | Tow tugs | |
| 1.5 | Max traction weight | kg | 2000 | 2500 |
| 1.6 | Rated pulling force | N | 700 | 800 |
| 1.7 | Wheelbase | mm | 650 | 650 |
| Weight | ||||
| 2.1 | Truck weight（with battery） | kg | 230 | 250 |
| 2.2 | Battery weight | kg | 50 | 70 |
| Tyre | ||||
| 3.1 | Tire type,Drive wheel/Bearing wheel | Rubber/PU | Rubber/PU | |
| 3.2 | Sizes of drive wheel （diameter×width） |
mm | 2×Φ300×100 | 2×Φ300×100 |
| 3.3 | Sizes of bearing wheel （diameter×width） |
mm | Φ250×75 | Φ250×75 |
| 3.4 | Sizes of Supporting wheel（diameter×width） | mm | Φ100×50 | Φ100×50 |
| 3.5 | Drive wheel/bearing wheel number （×=Drive wheel） |
mm | 2×/1 | 2×/1 |
| 3.6 | Front gauge | mm | 460 | 460 |
| Dimensions | ||||
| 4.1 | Overall height | mm | 1190 | 1190 |
| 4.2 | Height of tiller in drive position | mm | 1100 | 1100 |
| 4.3 | Hook height | mm | 235/285/335 | 235/285/335 |
| 4.4 | Overall length | mm | 1120 | 1120 |
| 4.5 | Overall width | mm | 700 | 700 |
| 4.6 | Ground clearance | mm | 100 | 100 |
| 4.7 | Turning radius | mm | 950 | 950 |
| Performance | ||||
| 5.1 | Drive speed load/unload | km/h | 3～6 | 3～6 |
| 5.2 | Rated pulling force | N | 700 | 800 |
| 5.3 | Max pulling force | N | 900 | 1100 |
| 5.4 | Max gradeability load/unload | % | 5/10 | 5/10 |
| 5.6 | Brake type | Electromagnetic | Electromagnetic | |
| Motor | ||||
| 6.1 | Drive motor rating S2 60min | kw | 1.1 | 1.2 |
| 6.2 | Charger (external) | V/A | 24/150 | 24/15 |
| 6.3 | Battery voltage/nominal capacity | V/Ah | 2×12/86 | 2×12/103 |
| 6.4 | Battery weight | kg | 50 | 70 |
| Others | ||||
| 7.1 | Type of drive control | DC | 0 | |
| 7.2 | Steering type | Mechanics | Mechanics | |
| 7.3 | Noise level | dB（A） | <70 | <70 |
| 7.4 | Type of trailer coupling | Latch | Latch | |
